Alternator for Bosch Mercedes Benz 12V 150A Lester 11042 0124615014

Model NO.: Lester 11042 0124615014
Structure: Cw
Current Level: 9(≥90A)
Brushless Alternator Type: Magnetizing Type
Voltage: 12V
Brand: Bosch
Rotation: Cw
Regulator Voltage Set Point: 14.5 ± 0.3 V
Trademark: ATL
Specification: Alternator 12V 150A
HS Code: 87081000
Type: Alternator
Rectifier Structure: Six Tubes
Bonding Type of Magnetic Field Winding: Inner Bonding
Voltage Adjuster Type: Electromagnetic Vibratory
Head Cover Position: Front
Alternator: 12V 150A
Output Tested: 12.8V
Net Weight: 7.05 Kg
Availability:
Quantity:
  • HBB081
  • HUB
  • 8511509000
Unit TypeAlternator
Part TypeUNIT
Voltage12
RotationCW
Amperage150
Pulley ClassS6
RegulatorIR
Fan TypeIF
ManufacturerBOSCH
BriefMERCEDES BENZ C, CLK, ML, SLK 2003-06
6-GROOVE PULLEY 50mm OD
SEARCH: 491202 (LATER VERSION)
DetailedThis is a Bosch 150A Alternator for Mercedes Benz Which Has the Typical Mercedes Mounting - the Mounting and Adjusting Ears are the Same Length and are at 2:00 and 6:00. The Plug is at 1:00 the Battery Stud is in the Rear at About 10:00 and the Unit Uses a Conventional 6-Groove Pulley.
ABO0251ARROWHEAD
11042LESTER
220-5149PIC
11042BBB
11042BBB NEW
186-1185BECK ARNLEY
0-124-615-014BOSCH
A-6436DIXIE
10689EXCEL
400-24108J & N
LRA03256LUCAS ELECTRICAL EUROPE
012-154-27-02MERCEDES BENZ
A2850USA INDUSTRIES
11042NWAI
1-3139-01BOWAI
90-15-6521WILSON
90-15-6521WILSON NEW
ALT10413WOOD AUTO
12433WORLDWIDE

MAKETYPEMODELYEARENGINEUnitTypeAEPLESTER









MERCEDES BENZAuto and Light TruckC CLASS20032.6LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckC CLASS20042.6LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckC CLASS20043.2LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckC CLASS20052.6LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckC CLASS20053.2LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckC CLASS20055.5LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckC CLASS20065.5LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckCLK CLASS20035.0LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckCLK CLASS20035.5LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckCLK CLASS20045.0LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckCLK CLASS20045.5LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckCLK CLASS20055.0LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckCLK CLASS20055.5LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckCLK CLASS20065.0LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckCLK CLASS20065.5LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckML CLASS20035.0LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckML CLASS20045.0LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckML CLASS20055.0LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckSLK CLASS20055.4LAlternatorABO025111042
MERCEDES BENZAuto and Light TruckSLK CLASS20065.4LAlternatorABO025111042

AEP NumberAEP (OEM)PART TYPE




BRG0007BF00M990405BEARING
BRG001635-4000EBEARING
BRG0078BF00M990434BEARING
ABO1615
COVER - RECTIFIER


PLUG CODE


PULLEY
ABO1119
RECTIFIER
ABO6074BF00M144136REGULATOR w/BRUSHES
ABO3030
ROTOR
ABO3502
SLIP RING
ABO4041
STATOR


TEST LEAD


THRU BOLT
